Saxsons PET tungsten syringe shields — 2 / 3 / 5 cc turn-lock variants with size-coded end caps (red, black, blue) and lead-glass viewing windows

PET shielding tier

tungsten workhorse chassis

Tungsten alloy

high-density shielding material

Syringe size range

full ladder in the sign-in matrix

Turn-lock + thumb-screw

syringe-retention mechanisms

Red · Black · Blue

size-coded end caps

ISO 9001 / 13485

Saxsons-manufactured

Authorised Indian Distributor

Saxsons Group

New Delhi, India · Since 1997

Nuclear MedicineNM-032Saxsons own-brand · Made in IndiaTungsten · high-density shieldingTurn-lock retention

Saxsons PET Tungsten Syringe ShieldTungsten Shielding for F-18 · Ga-68 · Lu-177 · Cu-64 Dispensing

Saxsons own-brand tungsten syringe shield engineered for PET radiopharmaceutical dispensing — F-18, Ga-68, Cu-64 — and Lu-177 theranostic prep. High-density tungsten-alloy shielding reduces finger dose to a fraction of the bare-syringe value; the engraved lead-glass viewing window keeps the dose volume visible while the shielding stays in place. Turn-lock retention on the dispense-line workhorse sizes, thumb-screw on the outlier sizes. Size-coded end caps in Red / Black / Blue make the right shield obvious at glance-speed. Designed and manufactured in India in an ISO 9001 / ISO 13485 approved plant. Sign in to view the complete configuration matrix.

Key Features

Saxsons own-brand product — designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. in an ISO 9001 / ISO 13485 approved plant
Tungsten-alloy shielding — high atomic number and high density deliver high attenuation per millimetre of shielding wall, keeping the chassis smaller and lighter
PET-tier shielding attenuates the annihilation radiation from F-18 and Ga-68 dispensing enough to bring extremity dose per dispense below the AERB / ICRP action threshold
Engraved lead-glass viewing window on the side — operator reads the calibration scale and visually confirms the dose volume without removing the shield
Turn-lock retention on the dispense-line workhorse sizes — one twist secures the syringe; no fiddly thumb-screw on the high-throughput dispense line

View all features

Enquire / Get Price← Nuclear Medicine Range

All Features

Saxsons own-brand product — designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. in an ISO 9001 / ISO 13485 approved plant
Tungsten-alloy shielding — high atomic number and high density deliver high attenuation per millimetre of shielding wall, keeping the chassis smaller and lighter
PET-tier shielding attenuates the annihilation radiation from F-18 and Ga-68 dispensing enough to bring extremity dose per dispense below the AERB / ICRP action threshold
Engraved lead-glass viewing window on the side — operator reads the calibration scale and visually confirms the dose volume without removing the shield
Turn-lock retention on the dispense-line workhorse sizes — one twist secures the syringe; no fiddly thumb-screw on the high-throughput dispense line
Thumb-screw retention on the outlier syringe sizes — accommodates the wider geometry range these sizes carry
Size-coded end caps in Red / Black / Blue — operator picks the correctly-sized shield at glance-speed; prevents wrong-size pick-up on the bench
Side-window variant + solid-tungsten (no-window) variant + bottom-draw-shield (BDS) variant available per workflow
Compact low-profile tungsten variant for ergonomic-first deployments where lighter handling weight matters more than maximum attenuation
Compatible with all standard luer-lock and slip-tip PET dispensing syringes (with PET-grade needles)
Tungsten chassis is corrosion-resistant and decontaminable; matt-finish to minimise glare under hot-lab lighting
Each shield laser-engraved with Saxsons brand mark + size designation for inventory tracking
Documentation: per-batch material certificate, lead-glass thickness certificate, ISO 9001 / 13485 quality records

Technical Specifications

Brand / build	Saxsons own-brand — manufactured in India by Saxsons Healthcare Pvt. Ltd., ISO 9001 / ISO 13485 approved plant
Shielding material	Tungsten alloy — high-density radiation-shielding grade
Shielding tier ladder	Multiple tungsten shielding tiers spanning the PET dispensing range — full ladder in the sign-in variant matrix
Syringe sizes supported	Full syringe-size range across the PET dispensing line — full ladder in the sign-in variant matrix
Retention mechanism	Turn-lock and thumb-screw retention across the range
Viewing window	Lead-glass side window with engraved calibration scale (standard); solid no-window variant available

End-cap colours	Red / Black / Blue — size-coded caps for glance-speed identification on the bench
Geometry variants	Side-window, no-window and bottom-draw-shield (BDS) geometries
Compatibility	Standard luer-lock and slip-tip PET dispensing syringes; pairs with the Saxsons Dose Cabinet and Lead-Lined Fume Hood
Compliance framework	AERB Safety Code for Nuclear Medicine Facility — extremity-dose protection; ICRP Publication 103 dose limits; ISO 9001 / ISO 13485
Documentation	Per-batch material certificate, lead-glass thickness certificate, ISO quality-record pack

Applications

Tungsten PET-tier shielding is the design choice between bare-syringe finger dose and the AERB limit

[¹⁸F]FDG unit-dose dispensing

Per-patient FDG dispensing — turn-lock shield sized to the routine unit-dose syringe. Operator reads the calibrated volume through the lead-glass window; dose is assayed against the dose-calibrator without ever exposing fingers to the bare syringe.

Ga-68 PET tracer dispensing

Turn-lock shield for Ga-68-DOTATATE / DOTATOC / PSMA-11 dispensing post-generator elution. The Red / Black / Blue size-coded caps make the right shield obvious at glance-speed against the bench tray.

Lu-177 theranostic dispensing

Higher-volume variants for Lu-177-DOTATATE and PSMA-617 patient-dose dispensing. Tungsten covers the Lu-177 photopeak and the annihilation contribution from Lu-177m in a compact chassis.

Cu-64 investigational dispensing

Investigator-initiated Cu-64 unit-dose dispensing for micro-dose research protocols. Standard PET tungsten attenuation applies across the Cu-64 emission profile.

Multi-size dispensing line

Size-coded caps let the radiopharmacist pick the right shield at glance-speed — Red, Black and Blue map onto the routine syringe sizes on the bench. Prevents wrong-size pick-up during the high-throughput dispensing shift; tray-level organisation by cap colour matches the daily syringe-size mix.

Hot-lab finger-dosimetry programme

TLD ring-badge programme — extremity-dose log records dose per dispense per operator. Tungsten PET-tier shielding is the design choice that keeps the annual extremity dose below the AERB 500 mSv occupational limit at typical PET workloads.

Why Saxsons PET Tungsten Syringe Shield?

Red · Black · Blue

Size-coded caps

The cap colour tells the operator which size shield they're holding before they read the engraving. On a busy PET dispensing line where 30+ doses pass through per shift, glance-speed size identification prevents the wrong-size shield being picked up and dispensed against.

Tungsten

PET shielding tier

Tungsten's high atomic number and high density mean the shielding wall stays thin while still bringing the primary annihilation flux down to a fraction of the bare-syringe surface. The compact chassis keeps the shield in hand for hours without operator fatigue on the high-throughput PET line.

500 mSv

AERB extremity dose limit

AERB caps the annual extremity (skin / fingers) dose for radiation workers at 500 mSv. A high-volume PET radiopharmacy dispensing 30+ FDG doses per shift can reach a measurable fraction of that limit with bare-syringe handling; a tungsten PET-tier shield brings the per-dispense extremity dose to a level the annual budget comfortably absorbs.

Peer-Reviewed Evidence — Saxsons PET Tungsten Syringe Shield

Why tungsten — the physics that gates PET syringe shielding

How tungsten delivers high per-millimetre attenuation at PET energies, the AERB / ICRP extremity-dose framework, why turn-lock matters for high-throughput dispensing lines, and how size-coded caps cut wrong-size pick-up at the bench.

Review the clinical validation data for Saxsons PET Tungsten Syringe Shield

✨ Configuration matrix · for signed-in customers

Detailed configurations are also available for your view

Shielding options across the isotope range, per-workflow ergonomics and colour-coding for the PET dispensing bench. Sign in or create a free Saxsons account to view.

Create free account →

Other benefits of a Saxsons account

Full configuration matrices across the whole Saxsons own-brand catalogue — shielding tiers, closures, accessories, per-workflow build sheets
Personal Literature Radar library — ★ save, ⌛ read-later and 📎 refer-later on peer-reviewed papers across theranostics, radiotherapy QA, dosimetry, hot-lab QC
Weekly literature digest — plain-text email summary of new peer-reviewed papers for the topics you follow
Faster quote turnaround — approved accounts skip the per-quote verification step and land straight with the Saxsons sales team
Per-site configuration proposals — request bespoke shielding drawings, vial-geometry inserts and site-IQ documentation
Early access to new Saxsons own-brand product launches, brochures and knowledge-hub content

Sign-up takes about 30 seconds — institutional email + hospital name. Accounts are reviewed by the Saxsons sales team. No promotional emails.

Variant matrix

Pick the size, the shielding tier, the variant

Five syringe sizes, three tungsten shielding tiers and three geometry variants. The per-isotope dispensing-line build sheet matches the size to the dose volume and the variant to the workflow geometry; the size-coded cap (Red = 2 cc, Black = 3 cc, Blue = 5 cc) makes the right shield obvious at glance-speed.

Sizes — sku · retention · workflow

Size	SKU	Retention	Typical use
1 cc	RPSS-1-9-9-T-P-N	Thumb-screw	Ga-68 / Cu-64 micro-dose dispensing; ¹/₂-ml clinical PET trials
2 cc	RPSS-2-9-9-T-P-N	Turn-lock	Low-volume PET tracer unit doses; second-line dispense
3 cc	RPSS-3-9-9-T-P-N	Turn-lock	Routine [¹⁸F]FDG / [¹⁸F]PSMA unit dose dispensing
5 cc	RPSS-5-9-9-T-P-N	Turn-lock	Theranostic Lu-177 PRRT / PSMA-617 dispensing; higher activities
10 cc	RPSS-10-9-9-T-P-N	Thumb-screw	Bulk Lu-177 patient-dose dispensing; multi-mL theranostic prep

Geometry variants

Lead-glass window (standard) T-P-N	9 mm tungsten shielding + side lead-glass window with calibration scale; the default operator-facing configuration
No lead-glass window T-A-N	Solid tungsten body without viewing window — for workflows where the dose is verified at the calibrator, not the shield
Bottom-draw shield (BDS) — 3 cc RPSS-3-9-9-T-P-BDS	Modified geometry for bottom-draw dispensing — sits over the dose-calibrator opening with the needle facing down; 3 cc syringe
Bottom-draw shield (BDS) — 5 cc RPSS-5-9-9-T-P-BDS	BDS variant in 5 cc; theranostic-prep bottom-draw workflow
Tungsten 2 mm low-profile 16-2-S-P-N	2 mm tungsten shield for low-energy + ergonomics-first deployments; lighter handle weight
Tungsten 5 mm SPECT-PET hybrid T-9-T-P-N	Mid-thickness tungsten variant; bridges SPECT and PET activity ranges with a lighter chassis
Lead-PET 9 mm — 2 cc RPSS-2-17-9-SS 202-T-P-N	Lead-based PET-tier alternative — 9 mm Pb in 2 cc; SS 202 outer + turn-lock + lead-glass window; for radiopharmacies preferring lead chassis over tungsten
Lead-PET 9 mm — 3 cc RPSS-3-17-9-SS 202-T-P-N	Lead-based PET-tier — 9 mm Pb in 3 cc workhorse syringe size
Lead-PET 9 mm — 5 cc RPSS-5-17-9-SS 202-T-P-N	Lead-based PET-tier — 9 mm Pb in 5 cc
Lead-PET 9 mm — 10 cc RPSS-10-17-9-SS 202-T-P-N	Lead-based PET-tier — 9 mm Pb in 10 cc bulk Lu-177 PRRT prep
Lead-PET 10 mm — 10 cc RPSS-10-17-10-SS 202-T-P-N	Heaviest Lead-PET variant — 10 mm Pb in 10 cc; for radiopharmacies stepping up from 9 mm tier

Accessories Matrix

Lead-glass viewing window	Operator reads the calibrated syringe volume through the shield; no open-close cycle per dispense
Turn-lock syringe retention (2 / 3 / 5 cc)	One-twist lock cycle in ≈ 1 s per dispense; built for the high-throughput PET line where 30+ doses per shift add up
Thumb-screw syringe retention (1 / 10 cc)	Wider geometry range on the smallest and largest syringe sizes; thumb-screw accommodates the off-standard barrel diameters
Size-coded end caps (Red 2 cc / Black 3 cc / Blue 5 cc)	Glance-speed syringe-size identification on the dispensing bench; prevents wrong-size shield pick-up during high-throughput shifts
Saxsons brand mark + size engraving	Inventory tracking and wrong-shield-for-syringe prevention at the bench; size designation engraved at the cap end
Matt-finish tungsten chassis	Reduces glare under hot-lab lighting; decontaminable wipe-down surface; corrosion-resistant for the daily-cleaning routine

Size-coded end caps

Cap colour	Syringe size	Workflow notes
Red cap	2 cc	Marks the 2 cc tungsten syringe shield — paediatric Tc-99m, low-volume Ga-68, Cu-64 micro-dose
Black cap	3 cc	Marks the 3 cc tungsten syringe shield — workhorse for [¹⁸F]FDG and routine PET unit-dose dispensing
Blue cap	5 cc	Marks the 5 cc tungsten syringe shield — theranostic Lu-177 PRRT / PSMA-617 dispensing and higher-activity work

Per-batch material certificate and lead-glass thickness certificate ship with every consignment. Cap colours are stocked variants and identify the syringe size (Red = 2 cc, Black = 3 cc, Blue = 5 cc).

Catalogs & Resources

AERB + ICRP + IAEA references that anchor the PET syringe-shielding decision. Contact Saxsons Healthcare for per-isotope shield-selection, India pricing and ISO documentation.

FILE

AERB Safety Code for Nuclear Medicine Facility

Indian regulatory framework for nuclear-medicine facility licensing including extremity-dose monitoring and shielded-dispensing expectations.

ReferenceDownload

FILE

ICRP Publication 103 — Recommendations of the International Commission on Radiological Protection

Current ICRP framework defining the 500 mSv annual extremity-dose limit for occupationally-exposed radiation workers.

ReferenceDownload

FILE

IAEA Operational Guidance on Hospital Radiopharmacy

IAEA framework covering hospital-radiopharmacy hot-lab design, operator protection and finger / extremity-dose monitoring practice.

ReferenceDownload

Saxsons own-brand · Variant brochure

Request the full Saxsons PET Tungsten Syringe Shield variant brochure

The detailed variant matrix, dimensions, accessories and AERB import documentation are not published on this page. Tell us who you are and a Saxsons sales engineer will email the brochure to your institutional address within one working day.

Brochure dispatch is reviewed by a sales engineer before sending — we may verify by phone.

Saxsons PET Tungsten Syringe Shield

More for this product

Each card opens a focused post for a specific specialty — peer-reviewed evidence and clinical workflow, written for the persona you select.

For Radiopharmacist

Radiopharmacist

Four isotope lines, one tungsten chassis, size-coded caps

Per-isotope dispensing-line workflow — F-18 / Ga-68 / Lu-177 / Cu-64 size + variant selection with AERB extremity-dose record entries per line. Cap colour identifies the syringe size (Red = 2 cc, Black = 3 cc, Blue = 5 cc).

Read this

FAQ

PET syringe shielding, 511 keV extremity dose — questions we hear from Indian PET / theranostics teams

Why 511 keV needs heavier shielding than 140 keV Tc-99m, why tungsten beats thicker lead on the injection ergonomics, how the shield keeps extremity dose under the AERB 500 mSv annual limit, and what the size + colour-cap matrix covers.

Q.Why does PET dispensing (F-18, Ga-68, Lu-177) need a heavier syringe shield than SPECT dispensing?

PET tracers emit 511 keV annihilation photons — the highest photon energy on the routine hot-lab bench. At 511 keV, the same shielding thickness of lead attenuates a fraction of what it does at 140 keV (Tc-99m). A 3 mm lead syringe shield that works comfortably for SPECT Tc-99m provides negligible protection against 511 keV — the technologist's finger dose accumulates fast on a busy PET day. PET dispensing needs either much thicker lead or a denser high-Z material.

Q.Why tungsten instead of thicker lead for 511 keV shielding?

Tungsten is significantly denser than lead, so the same photon-attenuation performance is achieved in a much smaller wall thickness. The Saxsons PET Tungsten Syringe Shield delivers 511 keV attenuation performance equivalent to a much heavier lead shield in a chassis the technologist can still hold and rotate for the injection — a lead equivalent of the same performance would be uncomfortably heavy and bulky for the injection ergonomics.

Q.What extremity-dose problem does this shield actually solve on a busy PET / theranostics day?

ICRP 103 / AERB dose limits set an annual extremity dose of 500 mSv. A radiopharmacist dispensing high-activity F-18, Ga-68 or Lu-177 doses without adequate 511 keV shielding can approach or exceed that limit within one to two years of routine work — extremity dose is the binding constraint on PET / theranostics-heavy departments, not whole-body dose. The tungsten shield keeps the operator finger dose per dispensing well below the limit budget so the technologist can run the PET day without a rotating-shift workaround.

Q.Which syringe sizes and isotopes does the shield family cover?

The family covers 1, 2, 3, 5 and 10 cc syringes with turn-lock (2, 3, 5 cc) and thumb-screw (1, 10 cc) closures. Colour-coded end caps (blue / red / black) provide per-isotope line separation on the dispensing bench — dedicated shields for F-18, Ga-68, Lu-177 and Cu-64 workflows so no cross-line contamination happens during a multi-tracer session.

Q.Is this a distributor-supplied shield or Saxsons-manufactured?

The PET Tungsten Syringe Shield is a Saxsons own-brand product — designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. under SKU NM-032. The lead-glass side window with engraved calibration scale, colour-coded end caps, size-family matrix and matt-finish tungsten chassis are engineered specifically for the dispensing workflows of Indian PET / theranostics NM departments.

Saxsons PET Tungsten Syringe Shield supplier in India — Saxsons Group

Saxsons Group has supplied nuclear medicine equipment to over 1,000 Indian hospitals since 1988. Every consignment of Saxsons PET Tungsten Syringe Shield ships with cold-chain logistics, AERB import documentation, CDSCO registration references and a Certificate of Analysis delivered before dispatch — the paperwork your radiation-safety and procurement teams need, pre-assembled.

Nationwide delivery footprint — every metro and tier-2 city in India, scheduled to your treatment / procedure calendar.
AERB & CDSCO documentation — import licence, radiation-safety paperwork and RSO briefing pre-assembled for the audit file.
40+ years in Indian oncology — long-standing supply relationships with AIIMS, Tata Memorial, and hundreds of tertiary-care centres.
Single point of accountability — one purchase order, one delivery contact, one after-sales team across the whole product family.
