Saxsons own-brand SPECT L-Bench engineered for routine SPECT dispensing (Tc-99m at 140 keV), I-131 thyroid-iodine work (364 keV) and β-γ mixed-emission isotopes (I-131, Y-90, P-32, Sr-89). Three lead tiers cover the energy range: 6 mm for SPECT, 12 mm for routine I-131, 25 mm for boosted-I-131 / high-activity therapy work. Optional β-γ hybrid build pairs 6 mm Pb with a 6 mm Perspex inner layer — Perspex handles the beta, lead handles the gamma, and the bremsstrahlung against the lead inner surface is contained. Outer finishes MS painted, SS 202 and SS 304. Sizes from the 13″×13″×17″ Ultra compact through the 18″×17″×26″ standard SPECT tabletop. Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. in an ISO 9001 / ISO 13485 approved plant.
| Brand / build | Saxsons own-brand — manufactured in India by Saxsons Healthcare Pvt. Ltd., ISO 9001 / ISO 13485 approved plant |
| Shielding tiers | 6 mm Pb (SPECT routine) · 12 mm Pb (I-131 routine) · 25 mm Pb (I-131 boosted / high-activity) |
| β-γ hybrid option | 6 mm Pb + 6 mm Perspex inner layer — for I-131 / Y-90 / P-32 / Sr-89 mixed-emission work |
| Footprint sizes | 13″×13″×17″ Ultra · 17″×18″×24″ mid · 18″×17″×26″ standard tabletop |
| Lead-glass viewing window | 12″ × 16″ × 8 mm wide format (standard tabletop) · 12.5″ × 8″ × 8 mm compact format (Ultra) · 8″ × 8″ × 4″ on the 25 mm I-131 tier |
| Outer material | MS (mild steel, epoxy-painted) or SS 202 / SS 304 (stainless steel) |
| Base / bottom-side lead | Optional BSL variants — covers the floor-scatter path (standard on SS 202 and SS 304 tabletop builds) |
| Target isotopes | Tc-99m (140 keV — routine SPECT) · I-131 (364 keV — thyroid / ablation) · Y-90 / P-32 / Sr-89 (β-γ hybrid) · Ga-67 / In-111 (compatible mid-energy SPECT) |
| Compliance framework | AERB Safety Code for Nuclear Medicine Facility · NCRP Report 49 / 147 shielding design · AAPM Report 88 quality assurance for radiopharmacy · ISO 9001 / ISO 13485 |
| Documentation | Per-batch lead-thickness certificate · lead-glass certificate · ISO quality-record pack |
Tc-99m, I-131 and β-γ mixed-emission isotopes across the SPECT and therapy-prep workflow
6 mm tier — Tc-99m-MDP, MIBI, ECD, MAG3, DMSA, sulphur colloid, pertechnetate. The 18″×17″×26″ standard tabletop or 13″×13″×17″ Ultra compact covers the per-shift workflow for routine cardiac / oncology / renal SPECT lists.
12 mm tier — I-131 capsule preparation for diagnostic uptake / scan (3–5 mCi) and post-thyroidectomy ablation prep at lower activities. The 364 keV gamma needs roughly twice the wall thickness of Tc-99m.
25 mm tier — I-131 ablation dispensing at 75–250 mCi for thyroid-cancer post-thyroidectomy ablation. Higher cumulative activity per shift means the shielding tier steps up; the 25 mm wall handles the cumulative dose-rate without exceeding AERB occupational limits.
6 mm Pb + 6 mm Perspex hybrid build — for pure-beta and mixed-emission therapy isotopes. Y-90 microspheres for SIR-T liver, P-32 for myeloproliferative disorders, Sr-89 for bone metastasis palliation. Perspex inner stops the beta, lead handles the gamma + bremsstrahlung.
6 mm tier covers Ga-67 (93, 184, 296, 388 keV mix) and In-111 (171, 245 keV doublet) at routine diagnostic activities. The same standard tabletop covers cardiac and oncology SPECT mixed-isotope lists.
13″×13″×17″ Ultra footprint for hot-labs where the SPECT bench has to sit between the dose calibrator and the fume hood. Same lead tier choices, narrower envelope, lead-glass window in the 12.5″×8″×8 mm compact format.
At 140 keV (Tc-99m photopeak) the half-value layer in pure lead is roughly 0.27 mm — so a 6 mm wall delivers roughly 22 HVL of attenuation (~ 99.99997 % of the primary photon flux removed). Routine SPECT dispensing at typical per-shift activity (10–20 GBq Tc-99m cumulative) sits comfortably inside this envelope.
I-131 emits at 364 keV — substantially harder than Tc-99m. The HVL in lead at 364 keV is roughly 3.0 mm; a 12 mm wall delivers ~ 4 HVL (~ 94 % attenuation). For high-activity ablation (75–250 mCi) the 25 mm tier delivers ~ 8 HVL (~ 99.6 % attenuation) which is the engineering choice for the therapy workflow.
Pure-beta isotopes (Y-90, P-32, Sr-89) need a low-Z absorber (Perspex / PMMA) on the inner surface — high-Z lead generates bremsstrahlung against the beta. The hybrid build is the right answer for the SIR-T microsphere line and the bone-pain palliation programme.
Variant matrix
Eight SPECT / I-131 / β-γ tier configurations from the Saxsons L-Bench family. The build sheet matches the lead tier to the dispense energy (140 / 364 keV), the β-γ hybrid to mixed-emission isotopes, the size to the hot-lab footprint and the outer material to the cleaning protocol.
| Item code | Lead | β option | Size (L×W×H) | Outer | Lead-glass window | Notes |
|---|---|---|---|---|---|---|
| RPLB-6-18-17-26-13-C-S-0 | 6 mm | — | 18″×17″×26″ | MS painted | 12″×16″×8 mm | Standard SPECT workhorse — Tc-99m routine dispensing |
| RPLB-6-18-17-26-SS 202-C-BSL-0 | 6 mm | — | 18″×17″×26″ | SS 202 | 12″×16″×8 mm | SS 202 outer · front-wall + base-side lead — standard SPECT tabletop |
| RPLB-6-18-17-26-SS 304-C-0-BSL-0 | 6 mm | — | 18″×17″×26″ | SS 304 | 12″×16″×8 mm | SS 304 outer · front-wall + base-side lead — clean-room / GMP-grade tabletop |
| RPLB-6-13-13-17-13-D-S-0 | 6 mm | — | 13″×13″×17″ | MS painted | 12.5″×8″×8 mm | L-Bench Ultra — compact 6 mm SPECT footprint |
| RPLB-6-17-18-26-13-C-P6-0 | 6 mm | 6 mm Perspex | 17″×18″×26″ | MS painted | 12″×16″×8 mm | β-γ hybrid — 6 mm Pb + 6 mm Perspex inner for I-131 / Y-90 mixed-emission work |
| RPLB-12-13-13-17-13-D-S-0 | 12 mm | — | 13″×13″×17″ | MS painted | 12.5″×8″×8 mm | Compact 12 mm tier — I-131 (364 keV) low-throughput dispensing |
| RPLB-12-18-17-26-13-C-S-0 | 12 mm | — | 18″×17″×26″ | MS painted | 12″×16″×8 mm | 12 mm I-131 standard tier — routine thyroid-iodine dispensing |
| RPLB-25-17-18-24-MS-A-0-S-0 | 25 mm | — | 17″×18″×24″ | MS painted | 8″×8″×4″ | 25 mm boosted-I-131 tier — high-activity I-131 therapy dispensing |
Accessories matrix
| Accessory / option | Why it matters in the hot lab |
|---|---|
| Lead-glass viewing window — 12″×16″×8 mm (wide) or 12.5″×8″×8 mm (compact) | Operator reads vial / syringe through the wall; wide format on the 17″+ benches, compact format on the 13″ Ultra. Standard 8 mm thickness gives adequate Pb-equivalence for the 140 / 364 keV SPECT range. |
| β-γ hybrid build — 6 mm Pb + 6 mm Perspex inner layer | For mixed-emission isotopes (I-131 with its β contribution, Y-90 / Sr-89 / P-32 pure beta). Lead handles gamma, Perspex inner-layer handles beta — without Perspex the high-energy beta generates bremsstrahlung against the inner lead surface. |
| Base / bottom-side lead (BSL variants) | Adds lead to the base of the L-bench worktop — covers the floor-scatter path. Standard on the SS 202 and SS 304 tabletop builds; specified per the structural-shielding plan. |
| Outer material — MS painted / SS 202 / SS 304 | MS for cost-optimised; SS 202 for upgraded cleaning durability at moderate cost; SS 304 for clean-room / GMP-grade hot-labs. Same lead-shielding mass inside any outer. |
| Tier-specific footprint | 13″×13″×17″ compact (Ultra), 17″×18″×24″ mid-size, 18″×17″×26″ standard SPECT tabletop. Picked per the hot-lab worktop layout. |
| Per-batch lead-thickness + lead-glass certificate | Documentation for AERB licence renewal and ISO 9001 / 13485 quality-record pack — every L-bench ships with traceable certificates. |
Per-batch lead-thickness certificate and lead-glass certificate ship with every L-bench. β-γ hybrid build pairs 6 mm front-wall Pb with a 6 mm Perspex inner sheet — Perspex stops the beta before bremsstrahlung can develop against the lead inner surface.
AERB + NCRP + AAPM + NIST references anchoring the SPECT and β-γ hybrid dispensing-bench design.
Indian regulatory framework for nuclear-medicine facility licensing — hot-lab shielding, dose-monitoring and dispensing-equipment expectations across SPECT and therapy isotopes.
Foundational NCRP shielding-design reference; energy-dependent HVL / TVL values across the SPECT / therapy energy range.
AAPM framework for radiopharmacy QC including shielded-dispensing-equipment expectations and operator-protection workflow.
Authoritative reference for photon attenuation coefficients in lead and lead-glass across 140 keV (Tc-99m), 364 keV (I-131) and pure-beta endpoint energies.
Saxsons™ SPECT L-Bench
Each card opens a focused post for a specific specialty — peer-reviewed evidence and clinical workflow, written for the persona you select.
Contact Saxsons Healthcare Pvt. Ltd. for tier + size + outer-material configuration, β-γ hybrid build, base / bottom-side-lead options, per-batch lead-thickness and lead-glass certificates, ISO documentation, and pairing with the Saxsons Dose Cabinet, Lead Vial Shield and SPECT Syringe Shield — designed and manufactured in India.
