Saxsons own-brand lead-lined syringe shield engineered for SPECT radiopharmaceutical dispensing — Tc-99m kits at 140 keV, I-131 at 364 keV, Ga-67 / In-111 / Tl-201 in between. 3 mm lead is the routine Tc-99m tier delivering > 99.95 % attenuation; 6 mm and 9 mm tiers step up for I-131 and the higher-energy SPECT isotopes. Five syringe sizes from 1 cc to 10 cc with thumb-screw lock and side lead-glass viewing window. SS-202 standard outer finish; SS-304 medical-grade option. Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. in an ISO 9001 / ISO 13485 approved plant.
| Brand / build | Saxsons own-brand — manufactured in India by Saxsons Healthcare Pvt. Ltd., ISO 9001 / ISO 13485 approved plant |
| Shielding material | Lead — high-density Pb shielding for SPECT energy range (80–400 keV) |
| Shielding tiers | 3 mm (Tc-99m routine) · 6 mm (high-activity SPECT / lower-tier I-131) · 9 mm (I-131 / Ga-67 / In-111) |
| Attenuation @ 140 keV (Tc-99m) | 3 mm Pb ≈ 11 HVL ≈ > 99.95 % attenuation |
| Attenuation @ 364 keV (I-131) | 9 mm Pb ≈ 3 HVL ≈ ~87 % attenuation (per-workflow risk-assessed; pairs with bench-side shielding for high-activity I-131 work) |
| Syringe sizes supported | 1 cc · 2 cc · 3 cc · 5 cc · 10 cc |
| Retention mechanism | Thumb-screw syringe lock (all sizes); holds the syringe square through the dispense cycle |
| Viewing window | Side lead-glass window with engraved calibration scale; matched to the surrounding lead thickness |
| Outer finish | SS-202 (standard) or SS-304 (medical-grade premium build) |
| Engraving | Saxsons brand mark + syringe-size designation embossed on the chassis |
| Compatibility | Standard luer-lock and slip-tip 1 / 2 / 3 / 5 / 10 cc SPECT dispensing syringes; pairs with Saxsons Dose Cabinet and Lead-Lined Fume Hood |
| Compliance framework | AERB Safety Code for Nuclear Medicine Facility — extremity-dose protection; ICRP Publication 103 dose limits; ISO 9001 / ISO 13485 |
| Documentation | Per-batch lead-thickness certificate, lead-glass thickness certificate, ISO quality-record pack |
3 mm lead is the routine Tc-99m tier; 6 / 9 mm steps cover the higher-energy SPECT range
Daily Tc-99m cold-kit dispensing — MDP (bone scan), MIBI (cardiac perfusion), ECD (brain perfusion), MAG3 (renal), DMSA (cortical renal). 3 mm lead is the workhorse tier; 3 cc shield is the workhorse size. > 99.95 % attenuation at the 140 keV photopeak keeps per-dispense extremity dose comfortably inside the annual budget.
9 mm lead tier for I-131 oral capsule decant and bulk-solution withdrawal. I-131 at 364 keV needs more lead per HVL than Tc-99m; the 9 mm tier delivers ~3 HVL of attenuation which the workflow pairs with bench-side shielding for higher-activity work.
6 mm or 9 mm tier for the higher-energy SPECT isotopes — Ga-67 (gallium scan, 93 / 184 / 296 keV), In-111 (Octreoscan / WBC labelling, 171 / 245 keV), Tl-201 (cardiac stress, 70–80 keV X-ray + low-intensity gamma). Tier selection follows the dominant photopeak energy per protocol.
1 cc and 2 cc sizes for paediatric Tc-99m kit dispensing where the volume per patient dose is much smaller. The smaller chassis is easier to handle for the careful low-volume aspiration paediatric work needs.
10 cc shield for Tc-99m bulk withdrawal from the generator eluate before per-patient dispense. The single-use bulk syringe carries the day's Tc-99m inventory; the 10 cc shield keeps the bulk handling extremity-dose-protected the same way the per-patient dispense is.
Per-batch lead-thickness certificate + lead-glass thickness certificate ship with every shield. The radiation-safety officer files the certificates in the per-instrument record; the AERB inspector reads them off the inspection dossier at the routine visit.
At 140 keV (the Tc-99m photopeak), the half-value layer in lead is roughly 0.27 mm. A 3 mm wall is roughly 11 HVL of lead — > 99.95 % attenuation of the primary photopeak. Going thicker on a Tc-99m shield adds chassis weight and operator fatigue with negligible dose-rate benefit; 3 mm is the engineered match between attenuation and ergonomics.
A typical Tc-99m dispensing dose-rate at the bare-syringe surface is on the order of millisieverts per hour; through 3 mm of lead it drops by more than three orders of magnitude. Per-dispense extremity dose with the shield in place sits comfortably below the level where the annual AERB 500 mSv extremity budget gets uncomfortable.
A SPECT facility that handles I-131 capsules or solution alongside Tc-99m needs a separate, thicker shield tier. The 9 mm lead variant covers I-131 (364 keV) to roughly 3 HVL — the workflow pairs the shield with bench-side shielding when the per-dispense activity is high.
Variant matrix
Five syringe sizes, three shielding tiers, two outer-chassis finishes plus the standard accessory pack. The per-isotope dispensing-line build sheet matches the size to the dose volume, the tier to the isotope energy, and the finish to the cleanroom-grade expectation.
Sizes — sku · workflow
| Size | SKU (3 mm Pb standard) | Typical use |
|---|---|---|
| 1 cc | RPSS-1-08-3-S-P-N | Paediatric Tc-99m unit doses; low-volume cold-kit dispense |
| 2 cc | RPSS-2-08-3-S-P-N | Low-volume Tc-99m kit doses; MAG3 / DMSA |
| 3 cc | RPSS-3-08-3-S-P-N | Routine Tc-99m kit dispensing — MDP, MIBI, ECD |
| 5 cc | RPSS-5-08-3-S-P-N | Higher-volume Tc-99m doses; bone-scan + cardiac perfusion |
| 10 cc | RPSS-10-08-3-S-P-N | Bulk Tc-99m withdrawal from generator eluate |
Accessories Matrix
| Lead-glass viewing window | Operator reads the calibrated syringe volume through the shield; no open-close cycle per dispense |
| Thumb-screw syringe lock | Holds the syringe square in the shield through the dispense cycle; finger access is only at the plunger end |
| Side calibration scale | Engraved scale aligned with the syringe graduations; operator confirms volume against the prescription without removing the shield |
| Saxsons brand mark + size engraving | Inventory tracking; size engraving prevents wrong-shield-for-syringe pick-up at the bench |
Per-batch lead-thickness certificate and lead-glass thickness certificate ship with every consignment. SKUs above are the 3 mm Pb standard variants; 6 mm and 9 mm tier SKUs follow the same pattern with the shielding designator updated.
Extended catalogue — β-γ + Perspex + Single Syringe Holders
β-γ hybrid syringe shields (Pb + Perspex inner) for pure-beta and mixed-emission isotopes, Perspex syringe shields for pure-beta work, and single-syringe holders (6 / 9 / 12 / 14 mm Pb) for bench-side syringe-holder applications.
| Variant | Item code | Description |
|---|---|---|
| β-γ hybrid syringe shield — 10 cc | RPSS-10-03-6-S-A-N | 10 cc syringe shield · 6 mm Pb + 6 mm Perspex inner · thumb-screw lock · no lead-glass window — for Y-90 / P-32 / Sr-89 / Lu-177 β-γ mixed-emission dispensing where Perspex stops the beta before bremsstrahlung against the lead inner |
| Perspex syringe shield — 20 cc | RPSS-20-A-6-AC-S-A-N | 20 cc syringe shield · 6 mm Perspex (no lead) · thumb-screw lock — for pure-beta isotopes where lead would generate bremsstrahlung; high-volume β work |
| Single syringe holder — 6 mm Pb | RPSSYH-2-10-09-6-A-S-0 | MS chassis · 2–10 cc syringe range · 6 mm Pb shielding · workshop-style single-syringe holder for the bench |
| Single syringe holder — 9 mm Pb | RPSSYH-2-10-17-9-A-S-0 | MS chassis · 2–10 cc syringe range · 9 mm Pb shielding · higher-tier holder |
| Single syringe holder — 12 mm Pb | RPSSYH-2-20-07-12-A-SH-0 | MS chassis · 2–20 cc syringe range · 12 mm Pb shielding · with shielding accessory; larger syringe range than the 9 mm tier |
| Single syringe holder — 14 mm Pb | RPSSYH-2-10-17-14-A-S-0 | MS chassis · 2–10 cc syringe range · 14 mm Pb shielding · highest single-holder Pb tier |
| Single syringe holder — handle SS 202 | RPSSYH-2-10-17-14-B-HAN-0 | SS 202 chassis · 2–20 cc syringe range · 14 mm Pb · WITH HANDLE — for hot-lab-to-bench portability of the held syringe |
AERB + ICRP + IAEA references that anchor the SPECT syringe-shielding decision. Contact Saxsons Healthcare for per-isotope tier selection, size matrix and India pricing.
Indian regulatory framework for nuclear-medicine facility licensing including extremity-dose monitoring and shielded-dispensing expectations.
Current ICRP framework defining the 500 mSv/year occupational extremity-dose limit.
IAEA framework covering hospital-radiopharmacy hot-lab design, operator protection and finger / extremity-dose monitoring practice.
