Saxsons own-brand shielded syringe carrier family for the routine task that drives a measurable share of operator extremity dose — moving dispensed unit-dose syringes from the hot lab to the patient injection room or theranostic suite. Lead tiers cover the dispense-energy range: 3 mm for SPECT Tc-99m, 6 mm for routine PET (FDG / Ga-68), 6 mm + 12 mm lateral for high-activity PET, and 12 mm for premium long-distance transport. β-γ hybrid builds pair lead with a Perspex or acrylic inner sheet for pure-beta and mixed-emission isotopes (Y-90, P-32, Sr-89, Lu-177 theranostic). SS 202 outer finish standard; SS 304 medical-grade option. Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. in an ISO 9001 / ISO 13485 approved plant.
| Brand / build | Saxsons own-brand — manufactured in India by Saxsons Healthcare Pvt. Ltd., ISO 9001 / ISO 13485 approved plant |
| Lead-shielding tiers | 3 mm Pb (SPECT) · 6 mm Pb (routine PET) · 6 mm + 12 mm lateral (high-activity PET) · 12 mm Pb premium |
| β-γ hybrid option | 3 mm Pb + 6 mm Perspex / acrylic inner — for Y-90 / P-32 / Sr-89 / Lu-177 theranostic work |
| Lu-177 hybrid carrier | Dedicated Pb + acrylic build (RPSYC-7-17-3-B-A-0) — handles β + γ from theranostic radiopharmaceuticals |
| Outer material | SS 202 (standard) · SS 304 (premium, clean-room compatible) |
| Chassis sizes | 199×83×66 mm (compact) · 201×88×66 mm (standard 6 mm) · 230×125×95 mm (12 mm) · 254×127×127 mm (Lu-177 hybrid) · 276×81×65 mm (β-γ 50 cc) |
| Carrying mechanism | Long-handle (colour-coded blue / red); both-hand or single-hand carry; ALARA distance |
| Target isotopes | Tc-99m · I-131 · Ga-67 · In-111 · F-18 · Ga-68 · Cu-64 · Lu-177 (theranostic) · Y-90 / P-32 / Sr-89 (β-γ hybrid) |
| Compliance framework | AERB Safety Code for Nuclear Medicine Facility · ICRP Publication 103 occupational dose framework · ISO 9001 / ISO 13485 |
| Documentation | Per-batch lead-thickness certificate · ISO quality-record pack |
The transport step is the hot-lab workflow that drives a measurable share of operator extremity dose
3 mm Pb tier covers the routine Tc-99m unit-dose walk from the dispensing bench to the gamma-camera injection room. Long handle keeps the operator hand at maximum distance from the shielded well.
6 mm Pb all-sides tier for the FDG / Ga-68 / Cu-64 unit-dose transport. High-activity tier (6 + 12 mm lateral) for the multi-dose source-vial radiopharmacies dispensing 30+ doses per shift.
Hybrid Pb + acrylic carrier handles the β contribution from Lu-177 and the γ doublet (113 / 208 keV). For PRRT and PSMA-617 unit-dose transport from radiopharmacy to therapy suite.
β-γ hybrid build with Perspex / acrylic inner — stops the high-energy beta before bremsstrahlung develops against the lead inner surface. For interventional-radiology SIR-T workflow.
6 mm or 12 mm Pb tier for high-activity I-131 ablation capsule transport — 75–250 mCi capsules carry to the patient room or therapy suite within AERB transport-shielding requirements.
Multi-syringe slot configuration carries 2–4 dispensed unit doses per trip. Reduces per-shift round trips between the hot lab and the injection room — operator cumulative-dose budget benefits proportionally.
Unlike a single-direction bench shield, the syringe carrier is held in the operator hand during transport — the lead has to wrap on all sides because there is no fixed orientation. The 6+12 mm lateral tier recognises that the lateral wall is closest to the operator hand during carry, so the lateral side gets the heaviest shielding.
Pure-beta isotopes (Y-90, P-32, Sr-89) generate bremsstrahlung when they stop in high-Z lead. A Perspex / acrylic inner layer stops the beta first at low Z; the lead behind handles the residual γ. This is the standard radiation-safety construction for any β-γ transport surface.
Dose rate from the shielded syringe well falls with the square of distance. The long-handle design adds 200–300 mm of distance between the operator hand and the shielded well — measurable reduction in cumulative extremity dose over a 100-shift year.
Variant matrix
Eleven carrier configurations from the Saxsons syringe carrier family — the build sheet matches the lead tier to the dispense energy, the β-γ option to the isotope mix and the chassis size to the per-trip dose volume.
| Item code | Lead | β option | Material | Use |
|---|---|---|---|---|
| RPSYC-1-08-3-C-S-0 | 3 mm | — | SS 304 | Compact 3 mm Pb · routine SPECT transport between hot-lab and injection room |
| RPSYC-1-08-3-B-S-0 | 3 mm | — | SS 202 | Standard 3 mm Pb · SPECT Tc-99m multi-syringe carrier |
| RPSYC-1-09-6-B-S-0 | 6 mm | — | SS 202 | 6 mm Pb on all sides · I-131 / Ga-67 / In-111 transport |
| RPSYC-1-09-12-B-S-0 | 6 mm + 12 mm (lateral) | — | SS 202 | 6 mm Pb 4 sides + 12 mm Pb lateral · PET (FDG / Ga-68) transport |
| RPSYC-4-17-6-B-S-0 | 6 mm | — | SS 202 | 6 mm Pb · larger 201×88×66 mm chassis · routine PET transport |
| RPSYC-1-07-12-B-S-0 | 12 mm | — | SS 202 | 12 mm Pb all sides · 230×125×95 mm · multi-syringe PET / I-131 |
| RPSYC-12-12-S.S-S.S-000 | 12 mm | — | SS · SS | 12 mm Pb · premium SS inner + outer · high-throughput PET radiopharmacy |
| RPSYC-7-17-3-B-A-0 | 3 mm + acrylic | Pb-acrylic hybrid | SS · 254×127×127 mm | Hybrid carrier for Lu-177 PRRT — handles β + γ from theranostic radiopharmaceuticals |
| RPSYC1-276-81-65-9-9-B-D-08-0 | 3 mm | 6 mm Perspex | SS 202 | 50 cc syringe · β-γ hybrid carrier · Y-90 / P-32 / Sr-89 work |
| RPSYC-201-86-76-9-9-B-08-0 | 3 mm | 6 mm acrylic | SS 202 outer · acrylic inner | 9″×9″ chassis · β-γ hybrid · compact PET / theranostic transport |
| RPSYC-6-20-3-B-B-0 | 3 mm | β-shield | 6×20 | Single 20 cc syringe carrier · β-γ shielding |
Accessories matrix
| Accessory / option | Why it matters in the workflow |
|---|---|
| SS 202 outer chassis (standard) | Hot-lab decontamination cycle; cost-optimised for routine SPECT and PET transport |
| SS 304 outer chassis (premium) | Clean-room / GMP-grade surface for daily wet wipe-down validation |
| β-γ hybrid build (Pb + Perspex / acrylic inner) | For mixed-emission isotopes (Y-90, P-32, Sr-89, Lu-177) where pure beta drives bremsstrahlung against the lead inner — Perspex / acrylic stops the beta first |
| Long-handle carry design | Operator hand stays at maximum distance from the shielded syringe well — ALARA distance principle applied to bench-to-injection-room transport |
| Multi-syringe slot configuration | Ferry 2–4 dispensed unit doses per trip; reduces the number of hot-lab-to-injection-room round trips per shift |
| Cleanable interior + exterior | Stainless steel inner and outer; spill-resistant; QA / contamination wipe-down stays inside the cleaning-validation schedule |
Indian regulatory framework for radioactive-material transport between rooms within a nuclear-medicine facility.
Current ICRP framework defining the 20 mSv/year average and 500 mSv/year extremity-dose occupational limits.
IAEA framework covering hospital-radiopharmacy operator protection during dispense-to-administer transport.
Saxsons™ Shielded Syringe Carrier
Each card opens a focused post for a specific specialty — peer-reviewed evidence and clinical workflow, written for the persona you select.
Contact Saxsons Healthcare Pvt. Ltd. for tier + outer-material + β option configuration, per-batch lead-thickness certificate, ISO documentation and pairing with the Saxsons Dose Cabinet, L-Bench, Fume Hood and syringe-shield range — designed and manufactured in India.
